Single-use endoscopic injection needle

The unique process treatment ensures the sharpness of the needle tip, which makes puncture more convenient and accurate, and multiple choices of needle tip length to ensure the practicality of surgery.

key word:

Single-use endoscopic injection needle

Category:

Gastrointestinal Endoscopy Series

Hotline:

15005279868

Message
Recommended products

Description

111



Characteristic

111
 Needle blade design, smooth and burr-free, easy to pierce and less painful.
111
 Ergonomic design, comfortable in the hand, clear point, easier to puncture.
111

High lubrication, high toughness PTFE tube, pushing resistance is smaller,

metal front end positioning, needle point position is more accurate.



1、The unique process treatment ensures the sharpness of the needle tip, which makes puncture more convenient and accurate, and multiple choices of needle tip length to ensure the practicality of surgery.

2、Ergonomic design of the handle, unique handle safety lock design, to ensure the convenience of operation.

3、Unique nozzle internal structure design, large spraying angle, small particles, simple operation and rapid spraying, to ensure the uniformity of spraying, improve the efficiency of surgery and reduce risk.

4、Adopt hard and transparent, acid and alkali resistant, super smooth PTFE outer tube to avoid distortion and ensure the fluidity of catheter insertion.



Application

lt is suitable for endoscopic mucosal injection.



Specifications

Model

Diameter(mm)

Length(mm)

Work clamp channel(mm)

Scope of application

FD/PSG-W1812

1.8

1200

≥Ø2.0

For bronchoscopy

FD/PSG-W1816

1.8

1600

≥Ø2.0

For ultra-fine gastroscopy

FD/PSG-W2416

2.4

1600

≥Ø2.8

For Gastroscopy

FD/PSG-W2419

2.4

1900

≥Ø2.8

For colonoscopy

FD/PSG-W2423

2.4

2300

≥Ø2.8

For colonoscopy

FD/PSG-L1812

1.8

1200

≥Ø2.0

For bronchoscopy/gastroscopy

FD/PSG-L1816

1.8

1600

≥Ø2.0

For ultra-fine gastroscopy

FD/PSG-L2416

2.4

1600

≥Ø2.8

For Gastroscopy

FD/PSG-L2419

2.4

1900

≥Ø2.8

For colonoscopy

FD/PSG-L2423

2.4

2300

≥Ø2.8

For colonoscopy

FD/PSG-Z1812-2503

1.8

1200

≥Ø2.0

For bronchoscopy

FD/PSG-Z1816-2504

1.8

1600

≥Ø2.0

For ultra-fine gastroscopy

FD/PSG-Z2418-2304

2.4

1800

≥Ø2.8

For Gastroscopy

FD/PSG-Z2423-2304

2.4

2300

≥Ø2.8

For colonoscopy

FD/PSG-Z2418-2305

2.4

1800

≥Ø2.8

For Gastroscopy

FD/PSG-Z2423-2305

2.4

2300

≥Ø2.8

For colonoscopy

FD/PSG-Z2418-2306

2.4

1800

≥Ø2.8

For Gastroscopy

FD/PSG-Z2423-2306

2.4

2300

≥Ø2.8

For colonoscopy

Note: Needle length 3, 4, 5, 6, and product length can be customized according to customer requirements.
